MC14024BDG
| Manufacturer Part | MC14024BDG |
|---|---|
| Manufacturer | onsemi |
| Description | IC COUNTER RIPPLE 7STAGE 14SOIC |
| Category | Integrated Circuits (ICs) |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Logic Type: | Binary Counter |
| Direction: | Up |
| Number of Elements: | 1 |
| Number of Bits per Element: | 7 |
| Reset: | Asynchronous |
| Timing: | - |
| Count Rate: | 12 MHz |
| Trigger Type: | Positive, Negative |
| Voltage - Supply: | 3 V ~ 18 V |
| Operating Temperature: | -55°C ~ 125°C |
| Mounting Type: | Surface Mount |
| Package / Case: | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package: | 14-SOIC |
