PDZ27BGWJ
| Manufacturer Part | PDZ27BGWJ |
|---|---|
| Manufacturer | Nexperia USA Inc. |
| Description | DIODE ZENER 27V 365MW SOD123 |
| Category | Discrete Semiconductor Products |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Voltage - Zener (Nom) (Vz): | 27 V |
| Tolerance: | ±2.48% |
| Power - Max: | 365 mW |
| Impedance (Max) (Zzt): | 40 Ohms |
| Current - Reverse Leakage @ Vr: | 50 nA @ 21 V |
| Voltage - Forward (Vf) (Max) @ If: | 1.1 V @ 100 mA |
| Operating Temperature: | 150°C (TJ) |
| Mounting Type: | Surface Mount |
| Package / Case: | SOD-123 |
| Supplier Device Package: | SOD-123 |
